Product Specifications
| Model: RGM | Glass (H1900mm) | Liner (H1900mm) | Tray (mm) |
|---|---|---|---|
| 900 x 750 | W870 x D720 | W880 x D730 | Rectangle 900 x 750 |
| 800 x 800 | W770 x D770 | W780 x D780 | Square 800 x 800 |
| 800 x 900 | W770 x D870 | W780 x D880 | Rectangle 800 x 900 |
| 900 x 900 | W870 x D870 | W880 x D880 | Square 900 x 900 |
| 1000 x 900 | W970 x D870 | W980 x D880 | Rectangle 1000 x 900 |
| 1000 x 1000 | W970 x D970 | W980 x D980 | Square 1000 x 1000 |
Features
| Component | Specifications |
|---|---|
| Glass | • Pivot door, reversible • Polished aluminium frame • Seals for water tightness • Chrome handle • Certified 6mm safety glass (AS/NZS 2208) • Nano coating easy clean glass |
| Liner | • 2mm acrylic • One piece • Flat • White |
| Tray | • 50mm profile tray • 20mm lip • Scratch resistant acrylic • Centre waste • 4 sides upstand |
Warranty
| Component | Warranty Period |
|---|---|
| Glass | 3 years |
| Parts | 1 year |
| Liner | 3 year |
| Tray | 1 year |
Important Notes
Note:
- Tapware and accessories not included
- Warranty void if recommended glue and sealant not used
Installation and Testing
The installation of this unit must be in accordance with industry standard practices, codes and guidelines. A licensed/registered industry professional must perform all plumbing/electrical works. Products should be pre-inspected on opening and rigorously tested/inspected for compliant performance and appearance immediately upon installation.
Specifications/measurements may change. Positions, measurements in the installation guides should in all situations be checked, re-measured before cutting, drilling or other fitting.
Compliance
All products sold meet NZ Building Code B2 Guarantees and Durability requirements plus all relevant Plumbing and AS/NZS Standards.
